In today's world, network traffic is increasing at an unprecedented rate, which makes it challenging for network administrators to manage and control the flow of data across various segments. To address this issue, Mylinking™ has developed a new product, the Network Packet Broker of ML-NPB-5660, which is designed to provide advanced traffic control and management capabilities for modern networks.
Features:
The Mylinking™ Network Packet Broker of ML-NPB-5660 is a high-performance network switch that comes with a range of features to help network administrators manage network traffic effectively. Firstly, it features 54 Ethernet ports, including 6 QSFP28 ports and 48 SFP28 ports, which can support 100G/40G Ethernet, 10G/25G Ethernet, and are backward compatible with 40G Ethernet. This means that the device can handle a large volume of network traffic from various sources.
Secondly, the device comes with a management interface that supports various management protocols, such as SNMP and SYSLOG. Additionally, it supports HTTP/Command Line Interface(CLI) remote and local management, which makes it easy for network administrators to configure and manage the device.
Thirdly, the Mylinking™ Network Packet Broker of ML-NPB-5660 supports Ethernet replication, aggregation, and load balance forwarding. This means that network administrators can ensure that traffic is flowing efficiently across the network and troubleshoot any issues that arise.
Fourthly, the device supports packet filtering and traffic guidance based on rules such as seven-tuple and the first 128-byte feature field of packets. This enables network administrators to ensure that only relevant traffic is transmitted across the network, thereby optimizing network performance.
Fifthly, the Mylinking™ Network Packet Broker of ML-NPB-5660 features hardware-level VXLAN, ERSPAN, and GRE encapsulation and packet header stripping, which enables efficient and secure transmission of network traffic. It also supports hardware nanosecond precise timestamping and packet slicing functions, which help network administrators to accurately monitor and analyze network traffic.
Applications:
The Mylinking™ Network Packet Broker of ML-NPB-5660 is designed to be used in various network environments, including data centers, service provider networks, enterprise networks, and cloud-based networks. It is particularly useful for organizations that handle large volumes of network traffic, such as financial institutions, healthcare organizations, and government agencies.
The device can be used for various applications, including network monitoring, traffic analysis, network security, and network optimization. For example, network administrators can use the device to monitor network traffic, identify potential security threats, and optimize network performance by ensuring that traffic is flowing efficiently across the network.
Specifications:
The Mylinking™ Network Packet Broker of ML-NPB-5660 has the following specifications:
1- 6 QSFP28 ports that support 100G/40G Ethernet, backward compatible with 40G Ethernet.
2- 48 SFP28 ports that support 10G/25G Ethernet.
3- 1 10/100/1000M adaptive MGT management interface.
4- 1 RS232C RJ45 CONSOLE port.
5- Supports Ethernet replication, aggregation, and load balance forwarding.
6- Packet filtering and traffic guidance based on rules such as seven-tuple and the first 128-byte feature field of packets.
7- Hardware-level VXLAN, ERSPAN, and GRE encapsulation and packet header stripping supported.
8- Maximum throughput of 1.8Tbps.
9- Support hardware nanosecond precise timestamp function.
10- Support hardware-level line speed Packet Slicing function.
11- HTTP/Command Line Interface(CLI) remote and local management.
12- SNMP management and SYSLOG management.
13- Dual power redundancy AC 220V/ DC-48 v (optional).
14- Advanced packet distribution processor
etc.
Plz visit here to get more Mylinking™ Network Packet Broker(NPB) ML-NPB-5660 details and specifications.
Post time: Mar-28-2023
